Product Description
Dependable vacuum is at the heart of evaporation, filtration, drying and degassing. VACUUBRAND pumps are engineered in Germany for long service life, low noise and efficient operation in the laboratory.
The VACUUBRAND 20751801 is the version of the EK 600 Base module for chemistry pumping unit (without pump). Chemistry-resistant models use fluoroplastic flow paths for corrosive vapors, and VARIO models adjust motor speed automatically to the process for faster, cleaner results. LIGHT LABS stocks the VACUUBRAND vacuum pump line so you can keep your lab supplied without delay.
Key Features
- Engineered for long service life and low maintenance
- Quiet, low-vibration operation
- Chemistry-resistant versions for corrosive vapors
- Variants with condensers, separators and controllers available
Specifications
| Catalog Number | 20751801 |
| Brand | VACUUBRAND |
| Product | EK 600 Base module for chemistry pumping unit (without pump) |
| Ambient temp., upper limit, in °C | 40 °C |
| Ambient temp., lower limit, in °C | 10 °C |
| Dimension L in mm | 118 mm |
| Dimension B in mm | 142 mm |
| Dimension H in mm | 412 mm |
| Outlet connection | small flange KF DN 25 |
| Inlet connection | Schlauchwelle DN 19 mm |
| For VACUUBRAND pumps | VACUU·PURE |
| Volume catchpot | 500 ml |
| Items supplied | Exhaust vapor condenser with KF DN 25 for VACUU·PURE |
| Pack Size | 1 each |
| Country of Origin | Germany |
Applications
- Rotary evaporation
- Vacuum filtration and drying
- Gel dryers and concentrators
- Degassing and distillation
