Product Description
Large culture flasks and heavy loads deserve an incubator shaker built to carry them. OHAUS incubating heavy-duty orbital shakers combine strong load capacity with excellent temperature uniformity from ambient +5°C to 65°C, at speeds from 15 to 500 rpm.
This listing is for OHAUS item number 30573769: Incubating Heavy Duty Orbital Shaker ISHD16HDG, 35 lb Capacity, 13 x 11 in Tray, 15-500 rpm, 120 V. A triple eccentric drive with brushless DC motor and a PID temperature controller keep both motion and temperature steady through long runs. The units are built from aluminum and Cycoloy and include an aluminum tray. Independent LED displays, temperature calibration, overload and over-temperature protection, a load sensor, RS232 output and TUV safety certification complete the package. Add it to your LIGHT LABS order and keep your lab running with genuine OHAUS equipment.
Key Features
- Heavy Load Capacity – handles substantial flask loads at low speed for large-volume cultures
- PID Temperature Control – ambient +5°C to 65°C with overshoot protection
- Triple Eccentric Drive – brushless DC motor for smooth, stable orbital motion from 15 to 500 rpm
- Independent LED Displays – temperature, speed and time shown simultaneously
- RS232 Communication – connect to a computer or printer for documentation
- Load Sensor and Overload Protection – safeguards the drive and samples
Specifications
| Item Number | 30573769 |
| Brand | OHAUS |
| Description | Incubating Heavy Duty Orbital Shaker ISHD16HDG, 35 lb Capacity, 13 x 11 in Tray, 15-500 rpm, 120 V |
| Motion | Orbital, 19 mm |
| Capacity | 35 lb (16kg)@ 75rpm, 5 lb (2.3kg)@ 500 rpm |
| Temp. Range | Ambient +5°C – 65°C |
| Speed Range | 15 rpm – 500 rpm |
| Tray Size | 13 in x 11 in (330 mm x 279 mm) (LxW) |
| Control | Digital |
| Calibration | Temperature calibration |
| Communication | RS232 |
| Dimensions | 25.5 in x 16 in x 14 in (648 mm x 406 mm x 356 mm) (LxHxW) |
| Drive System | Triple Eccentric;Brushless DC Motor |
| Inner Dimensions | 13.4 in x 9.5 in x 12 in (340 mm x 241 mm x 305 mm) (LxHxW) |
| Net Weight | 79.11 lb (35.9 kg) |
| Power | 120V, 5A, 50/60Hz |
| Power Consumption | 450 W |
| Safety Certification | TUV |
| Speed Accuracy | Above 100rpm +/- 1%, Below 100rpm /- 1 rpm |
| Timer | 1 s - 9,600 min |
| Tray Construction | Aluminum |
| Uniformity | ± 0.5°C at 37°C |
Related Models
Applications
- Cell cultures
- Solubility studies
- Bacterial suspensions
- Extraction procedures
- Large-flask fermentation
