Product Description
Store freezer boxes and conical tubes in the same slim rack. The Crystal Technology & Industries UFD-T15-222 Combination Upright Freezer Drawer Rack holds 4 standard 2" freezer boxes (2 deep x 2 high) plus up to 36 centrifuge tubes (15 mL), in a 11 5/16" deep rack.
Box compartments are 5 3/8 x 5 1/4 x 2 1/8" and fit standard 2" cardboard, fiberboard, and polycarbonate freezer boxes. Pull out a drawer to reach your samples without removing the whole rack from the freezer, so the rest of your inventory stays cold. The rack is built from pharmaceutical-grade stainless steel with double welds and smoothed edges, so it stays rigid and corrosion-free at -80°C. Each drawer has a handle and an identification card holder, and an optional security lock device is available separately.
The UFD-T15-222 is part of Crystal's drawer rack line for tubes, bottles, and combination storage. LIGHT LABS carries the full line so you can outfit every shelf in your freezer.
Key Features
- Holds 4 standard 2" boxes – 2 boxes deep x 2 boxes high
- Plus 36 tubes (15 mL) – Conical centrifuge tubes stored upright
- Mixed storage in one rack – Keep boxed aliquots and larger-volume samples together
- 11 5/16" deep x 9 11/16" tall – Fits upright freezer shelves
- Pharmaceutical-grade stainless steel – Corrosion-resistant and durable at ultra-low temperatures
- Double-welded construction – Rigid and long-lasting, with smoothed edges
- Optional security lock – Lock device sold separately
Specifications
| Catalog Number | UFD-T15-222 |
| Brand | Crystal Technology & Industries |
| Rack Type | Combination upright freezer drawer rack |
| Stores | Standard 2" freezer boxes and 15 mL conical centrifuge tubes |
| Capacity | 4 boxes + 36 tubes (15 mL) |
| Box Compartment (D x W x H) | 5 3/8 x 5 1/4 x 2 1/8 in (137 x 133 x 54.4 mm) |
| Material | Pharmaceutical-grade stainless steel, double welded, smoothed edges |
| Overall Dimensions (W x D x H) | 5 1/2 x 11 5/16 x 9 11/16 in (140 x 287 x 246 mm) |
| Lock | Security lock device available separately |
| Contents Included | No, rack only |
Choose Your Rack – Crystal Combination Drawer Racks
- UFD-T15-222 – 4 boxes (2") + 36 tubes (15 mL), 11 5/16" deep
- UFD-T15-322 – 6 boxes (2") + 60 tubes (15 mL), 16 11/16" deep
- UFD-T50-222 – 4 boxes (2") + 18 tubes (50 mL), 11 5/16" deep
- UFD-T50-322 – 6 boxes (2") + 30 tubes (50 mL), 16 11/16" deep
- UFD-XLT15-522 – 10 boxes (2") + 100 tubes (15 mL), 26 15/16" deep
- UFD-XLT50-522 – 10 boxes (2") + 51 tubes (50 mL), 26 15/16" deep
- UFD-XLB-522 – 10 boxes (2") + storage bottle drawer, 26 15/16" deep
More Crystal Drawer Racks
- Blood Sample Tube Drawer Racks – starting with UFD-T01-2
- Centrifuge Tube Drawer Racks – starting with UFD-T15-1
- Storage Bottle Drawer Racks – starting with UFD-XLB-1
Applications
- Projects that combine boxed aliquots with larger-volume samples
- Storage in -80°C and -20°C upright freezers
- Biobanking and specimen inventory management
- Clinical, research, and pharmaceutical laboratories
