Product Description
Sorting SBS-footprint boxes by drawer rather than by stack means no more unloading a column to reach the box on the bottom. Crystal's UFDMX series holds SBS-format boxes in 12 configurations, from 3 deep x 3 high to 6 deep x 5 high.
This listing is for Crystal catalog number UFDMX-632, the Drawer-Style Upright Freezer Rack for SBS-Footprint Boxes. Every rack is pharmaceutical-grade stainless steel, double welded and edged smooth for safe handling with cold gloves. The front-opening drawer layout lets each box slide out on its own, cutting the time the freezer door stays open. LIGHT LABS stocks Crystal freezer racks and ships them quickly from Englewood, Colorado.
Key Features
- SBS-Footprint Storage – compartments are sized for SBS-format boxes
- 12 Configurations – 9 to 30 box positions to match shelf depth and height
- Pharmaceutical-Grade Stainless Steel – built from pharmaceutical-grade stainless steel that holds up to repeated freeze-thaw cycles and routine cleaning
- Double-Welded Construction – double-welded joints and smoothed edges keep the rack rigid and protect gloves and hands during handling
- Individual Drawer Access – each box slides out on its own for quick retrieval
- Lifetime Warranty – Crystal backs all of its rack products with a lifetime warranty
Specifications
| Catalog Number | UFDMX-632 |
| Brand | Crystal Technology & Industries |
| Box Type / Fits | SBS-format boxes |
| Configuration | 6 deep x 3 high |
| Box Capacity | 18 boxes |
| Material | Pharmaceutical-grade stainless steel |
| Construction | Double welded with smoothed edges |
| Rack Style | Upright freezer drawer rack |
| Box Format | SBS-format boxes |
| Warranty | Lifetime warranty on rack products |
Other Configurations
- UFDMX-332 – 3 Deep x 3 High (9 Boxes)
- UFDMX-342 – 3 Deep x 4 High (12 Boxes)
- UFDMX-352 – 3 Deep x 5 High (15 Boxes)
- UFDMX-432 – 4 Deep x 3 High (12 Boxes)
- UFDMX-442 – 4 Deep x 4 High (16 Boxes)
- UFDMX-452 – 4 Deep x 5 High (20 Boxes)
- UFDMX-532 – 5 Deep x 3 High (15 Boxes)
- UFDMX-542 – 5 Deep x 4 High (20 Boxes)
- UFDMX-552 – 5 Deep x 5 High (25 Boxes)
- UFDMX-642 – 6 Deep x 4 High (24 Boxes)
- UFDMX-652 – 6 Deep x 5 High (30 Boxes)
Applications
- SBS-format sample box storage
- Screening and compound libraries
- Upright -80°C freezer organization
- Core facility sample management
