Product Description
Stop pulling an entire rack out of the freezer to reach one box at the back. These drawer racks put standard boxes in pull-out drawers, with 3" box versions from 2 deep x 2 high to 5 deep x 4 high plus 2" and 5" box models.
This listing is for Crystal catalog number UFD-542, the Upright Freezer Drawer Rack for 2" Boxes. Each rack is made of pharmaceutical-grade stainless steel, double welded, with smoothed edges. The drawers slide forward to bring any box within reach, and lock devices are ordered separately for the 3" box models. LIGHT LABS can help you match Crystal racks to your freezer shelves and storage boxes.
Key Features
- Pharmaceutical-Grade Stainless Steel – double welded construction with smoothed edges stands up to repeated freeze cycles and protects gloves during handling
- Pull-Out Drawers – reach rear boxes quickly and limit time with the freezer door open
- Wide Size Range – 2 to 5 deep and 2 to 5 high to match common freezer shelf layouts
- 3" Box Compartments – 3 x 5 7/16 x 5 1/4 in (75.9 x 137.4 x 133 mm)
- Optional Security Lock – a lock device is available and ordered separately for the 3" box models
- Lifetime Warranty – Crystal backs all rack products with a lifetime warranty
Specifications
| Catalog Number | UFD-542 |
| Brand | Crystal Technology & Industries |
| Box Type / Fits | Standard 2" boxes |
| Configuration | 5 deep x 4 high |
| Box Capacity | 20 boxes |
| Overall Dimensions (H x W x D) | 9 7/16 x 5 1/2 x 27 in (240 x 140 x 686 mm) |
| Compartment Dimensions (H x W x D) | 2 1/8 x 5 1/4 x 5 3/8 in (54.4 x 133 x 137.4 mm) |
| Pack Size | 1 each |
| Material | Pharmaceutical-grade stainless steel |
| Construction | Double welded with smoothed edges |
| Access | Pull-out drawers |
| Warranty | Lifetime warranty on rack products |
Other Configurations
- UFD-222
- UFD-223 – 2 Deep x 2 High (4 Boxes)
- UFD-232
- UFD-233 – 2 Deep x 3 High (6 Boxes)
- UFD-242
- UFD-243 – 2 Deep x 4 High (8 Boxes)
- UFD-252
- UFD-262
- UFD-323 – 3 Deep x 2 High (6 Boxes)
- UFD-332
- UFD-333 – 3 Deep x 3 High (9 Boxes)
- UFD-342
- UFD-343 – 3 Deep x 4 High (12 Boxes)
- UFD-352
- UFD-362
- UFD-423 – 4 Deep x 2 High (8 Boxes)
Applications
- -80°C upright freezer sample storage
- 3" box storage for tall cryovials
- Clinical trial sample archives
- Biobank inventory management
