Product Description
The biggest rack in Crystal's 4-deep drawer line holds twenty-eight boxes in a single 5 1/2" wide column. The Crystal Technology & Industries UFD-472 Upright Freezer Drawer Rack stores twenty-eight standard 2" freezer boxes, four boxes deep by seven boxes high, across seven full-depth pull-out drawers. Each drawer brings a row of four boxes forward for easy access, even on the deepest freezer shelves.
Unlike the 6-high UFD-262, UFD-362, and UFD-462, the UFD-472 keeps the full 2 1/8" compartment height, so it fits standard 2" cardboard, fiberboard, and polycarbonate freezer boxes. It's made from pharmaceutical-grade stainless steel with double welds for rigidity under a full load at -80°C, and all edges are smoothed for comfortable, safe handling.
At 16 1/2" tall, the UFD-472 is designed for freezers with tall shelf openings, where it delivers maximum storage density per shelf. Get the most out of your freezer with the UFD-472 and the full Crystal drawer rack line from LIGHT LABS.
Key Features
- Full-depth pull-out drawers – Bring all four boxes in a row forward without removing the rack
- Holds 28 standard 2" boxes – 4 boxes deep x 7 boxes high, the highest capacity in the 4-deep drawer line
- Full-height 2 1/8" compartments – Fit cardboard, fiberboard, and polycarbonate 2" boxes
- Pharmaceutical-grade stainless steel – Corrosion-resistant and durable at ultra-low temperatures
- Double-welded construction – Stays rigid even when fully loaded
- Smoothed edges – Safer, more comfortable handling
- Maximum storage density – 28 boxes in a 5 1/2" wide footprint
- Less door-open time – Find and remove samples quickly to protect freezer temperature
Specifications
| Catalog Number | UFD-472 |
| Brand | Crystal Technology & Industries |
| Rack Type | Upright freezer drawer rack |
| Box Size | Standard 2" boxes |
| Configuration | 4 boxes deep x 7 boxes high |
| Total Capacity | 28 boxes |
| Material | Pharmaceutical-grade stainless steel, double welded |
| Overall Dimensions (W x D x H) | 5 1/2 x 22 5/16 x 16 1/2 in (140 x 566 x 419 mm) |
| Compartment Dimensions (W x D x H) | 5 1/4 x 5 3/8 x 2 1/8 in (133 x 137.4 x 54.4 mm) |
| Boxes Included | No, rack only |
Choose by Configuration – 4-Deep Drawer Racks for 2" Boxes
- UFD-432 – 4 deep x 3 high, 12 boxes
- UFD-442 – 4 deep x 4 high, 16 boxes
- UFD-452 – 4 deep x 5 high, 20 boxes
- UFD-462 – 4 deep x 6 high, 24 boxes (ideal for cardboard boxes)
- UFD-472 – 4 deep x 7 high, 28 boxes
Need a Shorter Rack?
- UFD-452 – 4 deep x 5 high, 20 boxes, 11 13/16" tall, for standard shelf openings
Drawer Rack or Side-Access Rack?
- Drawer Rack (UFD Series) – Pull out one drawer to see and reach every box in that row. Best for frequently accessed samples and for reaching boxes at the back of deep racks.
- Side-Access Rack (UF Series) – Boxes slide in and out of open compartments from the side. Best for maximum capacity and lowest cost per box position.
Applications
- Sample storage in -80°C and -20°C upright freezers
- Biobanking and high-volume specimen inventory
- Storage of cryovials, microtubes, and aliquots in 2" boxes
- Maximizing storage density on tall freezer shelves
- Clinical, research, and pharmaceutical laboratories
