Product Description
LIGHT LABS is proud to offer the Crystal Technology & Industries Stainless Steel Vertical Freezer Rack with Spring Clips for Standard 2" Boxes (Cat # CF-10-2-S). This rugged vertical rack stores ten standard 2" freezer boxes in a single column, stacked 10 boxes high, for laboratory chest freezers and liquid nitrogen (LN2) tanks. Integrated spring clips hold each box in place, so boxes stay put when the rack is lifted, tilted, or moved. That cuts the risk of a box sliding out and dropping samples into the freezer or onto the floor.
The spring clips are what set the CF-10-2-S apart from the standard CF-10-2. They give each box its own built-in retention, without loose locking rods to handle while you're wearing cryogenic gloves. The rack is made of pharmaceutical-grade stainless steel with double-welded joints for strength and long-term durability at ultra-low and cryogenic temperatures. All edges are smoothed for safe handling. Each of the ten compartments measures 2 3/16" x 5 5/16" x 5 5/16" and accepts standard 2" cryoboxes and freezer boxes in fiberboard, cardboard, or plastic. A built-in handle at the top makes lifting the rack in and out of the freezer quick and easy.
The CF-10-2-S is sold as a rack only. Storage boxes are not included, so you can use your existing 2" boxes. Pre-configured versions with 2" boxes and 81-cell or 100-cell dividers are also available. For added security, an optional lock device is sold separately. LIGHT LABS is your trusted source for laboratory freezer racks and cold storage solutions.
KEY FEATURES
- Integrated spring clips — hold each box securely in place when the rack is lifted or tilted
- Holds 10 standard 2" boxes — single-column vertical design, 10 boxes high
- For chest freezers and LN2 tanks — lowers straight down for efficient top-access storage
- Pharmaceutical-grade stainless steel — corrosion resistant and durable at ultra-low and cryogenic temperatures
- Double-welded construction — strong, rigid, built for long-term use
- Smoothed edges — safe handling, even with cryogenic gloves
- Built-in handle — easy lifting in and out of the freezer
- Rack only — use your existing 2" fiberboard, cardboard, or plastic boxes
- Versions with boxes available — with 81-cell (CF-10-2-S-W-81) or 100-cell (CF-10-2-S-W-100) dividers
- Optional lock device — sold separately
- Made by Crystal Technology & Industries
SPECIFICATIONS
| Attribute | Detail |
|---|---|
| Catalog Number | CF-10-2-S |
| Brand | Crystal Technology & Industries |
| Product Name | Stainless Steel Vertical Freezer Rack with Spring Clips for Standard 2" Boxes |
| Rack Type | Vertical (top-access) |
| Box Retention | Integrated spring clips |
| Box Capacity | 10 boxes (1 column x 10 high) |
| Box Size | Standard 2" freezer boxes |
| Material | Pharmaceutical-grade stainless steel |
| Construction | Double-welded, smoothed edges |
| Handle | Yes, built-in |
| Freezer Compatibility | Chest freezers, LN2 tanks |
| Overall Dimensions | 22 5/16" x 5 5/8" x 5 1/2" (566 x 143 x 140 mm) |
| Compartment Dimensions | 2 3/16" x 5 5/16" x 5 5/16" (55 x 135 x 135 mm) |
| Boxes Included | No (rack only) |
| Lock Device | Sold separately |
CF-10-2-S (SPRING CLIPS) vs. CF-10-2 (STANDARD) — WHICH RACK DO YOU NEED?
| Feature | CF-10-2-S | CF-10-2 |
|---|---|---|
| Box Retention | Integrated spring clips on each compartment | Optional lock device |
| Box Capacity | 10 x 2" boxes | 10 x 2" boxes |
| Material | Pharmaceutical-grade stainless steel | Pharmaceutical-grade stainless steel |
| Overall Dimensions | 22 5/16" x 5 5/8" x 5 1/2" | 22 5/16" x 5 5/8" x 5 1/2" |
| Freezer Compatibility | Chest freezers, LN2 tanks | Chest freezers, LN2 tanks |
| Best For | Frequent handling, tilting, or transport where boxes must stay put | General organized storage at the lowest cost |
ORDERING INFORMATION — CRYSTAL 10-HIGH VERTICAL RACKS FOR 2" BOXES
| Cat # | Description |
|---|---|
| CF-10-2-S | Stainless Steel Vertical Rack with Spring Clips, 10 Boxes High, rack only |
| CF-10-2-S-W-81 | Stainless Steel Vertical Rack with Spring Clips, 10 Boxes High, with 2" boxes and 81-cell dividers |
| CF-10-2-S-W-100 | Stainless Steel Vertical Rack with Spring Clips, 10 Boxes High, with 2" boxes and 100-cell dividers |
| CF-10-2 | Stainless Steel Vertical Rack, 10 Boxes High, rack only |
| CF-10-2-W-81 | Stainless Steel Vertical Rack, 10 Boxes High, with 2" boxes and 81-cell dividers |
| CF-10-2-W-100 | Stainless Steel Vertical Rack, 10 Boxes High, with 2" boxes and 100-cell dividers |
APPLICATIONS
- Secure storage of 2" cryoboxes in chest freezers (−20°C, −80°C)
- Vapor-phase and liquid-phase LN2 tank storage
- Racks that are frequently lifted, tilted, or moved between freezers
- Biorepository and biobank sample organization
- Cryovial storage for cell lines, stem cells, and primary cells
- DNA, RNA, protein, and serum sample archiving
- Any laboratory application requiring durable vertical storage with built-in box retention
